20 Inch S32750 Duplex ERW EFW Welded Stainless Steel Pipe

Contact Now

20 Inch S32750 Duplex ERW EFW Welded Stainless Steel Pipe

Minimum Order Quantity :	negotiable	Price :	2400-12000USD/TON
Packaging Details :	Plywood Case / Bundles	Delivery Time :	30 Days
Payment Terms :	T / T ; L / C	Supply Ability :	500 Tons / Month

Place of Origin:	CHINA	Brand Name:	MTSCO
Certification:	ISO 9001 & PED & AD2000	Model Number:	MTSCOSSSP62

Detail Information
Material:	S32750 / 2507	NDT:	Eddy Current Or Hydraulic Test
Inspection:	100%	Surface:	Pickling
Length:	5800mm
Highlight:	EFW Welded Stainless Steel Pipe , ERW Welded Stainless Steel Pipe , S32750 Duplex Stainless Steel Pipe

Product Description

20Inch S32750 Duplex Stainless Steel ERW / EFW Welded Pipe

ASTM A269 - 10 : Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service

ASTM A312 / A312M - 12 : Standard Specification for Seamless , Welded , and Heavily Cold Worked Austenitic Stainless Steel Pipes
ASTM A789 / A789M - 10a : Standard Specification for Seamless and Welded Ferritic / Austenitic Stainless Steel Tubing for General Service
ASTM A790 / A790M - 11 : Standard Specification for Seamless and Welded Ferritic / Austenitic Stainless Steel Pipe

Specifications :

DN	NPS(Inch)	D(mm)	SCH5S	SCH10S	SCH10	SCH20	SCH30	STD	SCH40	SCH60	SCH80	XS
300	12	323.9	3.96	4.57	-	6.35	8.38	9.53	10.31	14.27	17.48	12.7
350	14	355.6	3.96	4.78	6.35	7.92	9.53	9.53	11.13	15.09	19.05	12.7
400	16	406.4	4.19	4.78	6.35	7.92	9.53	9.53	12.7	16.66	21.44	12.7
450	18	457.2	4.19	4.78	6.35	7.92	11.13	9.53	14.27	19.05	23.83	12.7
500	20	508	4.78	5.54	6.35	9.53	12.7	9.53	15.09	20.62	26.19	12.7
550	22	559	4.78	5.54	6.35	9.53	12.7	9.53	-	22.23	28.58	12.7
600	24	610	5.54	6.35	6.35	9.53	14.27	9.53	17.48	24.61	30.96	12.7
650	26	660	-	-	7.92	12.7	-	9.53	-	-	-	12.7
700	28	711	-	-	7.92	12.7	15.88	9.53	-	-	-	12.7
750	30	762	6.35	7.92	7.92	12.7	15.88	9.53	-	-	-	12.7
800	32	813	-	-	7.92	12.7	15.88	9.53	17.48	-	-	12.7
850	34	864	-	-	7.92	12.7	15.88	9.53	17.48	-	-	12.7
900	36	914	-	-	7.92	12.7	15.88	9.53	19.05	-	-	12.7
950	38	965	-	-	-	-	-	9.53	-	-	-	12.7
1000	40	1016	-	-	-	-	-	9.53	-	-	-	12.7
1050	42	1067	-	-	-	-	-	9.53	-	-	-	12.7
1100	44	1118	-	-	-	-	-	9.53	-	-	-	12.7
1150	46	1168	-	-	-	-	-	9.53	-	-	-	12.7
1200	48	1219	-	-	-	-	-	9.53	-	-	-	12.7

UNS Designation	C	Si	Mn	P	S	Cr	Ni	Mo	N	Cu
UNS Designation	max	max	max	max	max	Cr	Ni	Mo	N	Cu
S31803	0.03	1	2	0.03	0.02	21.0 - 23.0	4.5 - 6.5	2.5 - 3.5	0.08 - 0.20	-
S32205	0.03	1	2	0.03	0.02	22.0 - 23.0	4.5 - 6.5	3.0 - 3.5	0.14 - 0.20	-
S32750	0.03	0.8	1.2	0.035	0.02	24.0 - 26.0	6.0 - 8.0	3.0 - 5.0	0.24 - 0.32	0.5 max
S32760	0.05	1	1	0.03	0.01	24.0 - 26.0	6.0 - 8.0	3.0 - 4.0	0.20 - 0.30	0.50 -1.00

Application :

1 . For fluid and gas transport

2 . Structure and machining

3 . Heat exchanger pipes etc

Advantages :

1 . Superior surface finish

2 . Better mechanical property

3 . More precise dimension

4 . Perfect inspection method and inspection equipment

Test :

1 . X-ray , Size test , Length test

2 . Chemical Analysis ( Photoelectric Emission Spectroscopic ) etc

Terms & Conditions	Price Item	FOB, CFR, CIF or as negotiation
	Payment	T/T, LC or as negotiation
	Delivery Time	30 working days after received your deposit (Normally according to the order quantity)
	Package	Iron case; woven bag or as per customer’s requirement
	Quality Requirement	Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality	Test	NTD(Ultrasonic test, Eddy Current test);
		Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test);
		Metal Test(Metallographic Analysis, Impact Test-High/low temperature);
		Chemical Analysis(Photoelectric Emission Spectroscopic)
Market	Main Market	Europe, Middle East, Southeast Asia, South America. etc
